Description
Woobu Upa Included Versions:
-
Print-in-Place Version: No assembly required, optimized for seamless single-print results
-
Split-to-Parts Version: Ideal for detailed color changes and higher quality finishes
Printing Recommendations:
General Settings:
-
Walls: 3
-
Infill: 15% Gyroid or 3D Honeycomb
-
Supports: Not required
-
Brims: Recommended with a 0.3mm brim gap (especially on textured PEI plates)
Layer Height:
-
Split Parts Version:
-
0.12mm layer height for all components except the body
-
0.2mm layer height is acceptable for the body
-
Top Surface Pattern:
-
Use Concentric for best visual results
Scaling Guidelines:
-
Print-in-Place Version: Tested down to 50%, recommended 70% or higher
-
Split Parts Version: Tested up to 120%, not recommended to scale down
If tolerance issues arise during assembly, scale individual parts up or down by 2% as needed. Always scale face components together.
Magnet Version (Optional Faceplate):
-
Magnet Size: 5x3mm round (available on Amazon)
-
Fish magnet included for hidden magnetic faceplate feature
IMPORTANT:
If using the hidden magnet fish version, insert magnets by pausing at layer 20.
Do not use this version without a magnetic build plate, as loose magnets can stick to the nozzle and damage your printer.
Multi-Material (3MF) Notes:
-
Do not use slicer’s fill tool for faceplate or eyes — assign colors via the object list
-
Avoid “Split to Objects” function to preserve clean edges and color fidelity
